OS-AS100GOX 12T/Hr WATER OZONE GENERATOR

ozone output : 100g/hr
ozone water flow : 12m3/hr...

FeedbackTelephone
+8617503097613
Details Introduction

Product characteristics

1. Corona discharge technology is adopted, and there is an efficient mixing system, which can directly mix with water to produce high concentration ozone water.

2. Automatic intelligent control,Press the button to produce high concentration ozone water.

3. For general water treatment, no need to connect other external equipment, directly connected to the pipeline can be used.

OS-AS100G - 副本.jpg

Product Application

For water treatment can choose water aeration mixing, Venturi mixer mixing, gas-liquid mixing pump and stainless steel ozone reaction tank for different application.

1. Clean and disinfect packaging bottles and processing equipment of food and beverage enterprises and biological enterprises.

2. Mineral water, purified water, sterile water, tap water sterilization and disinfection; Disinfection of water provided by each production enterprise.

3. Aquaculture sterilization and disinfection of aquaculture water to prevent aquatic diseases.

4. Sterilization and disinfection of agricultural products such as vegetables and fruits to reduce pesticide residues.

5. Cleaning and disinfecting tableware, drink ware and tea set in restaurants, canaries, hotels, etc.

6. Raw water treatment, tap water treatment, wastewater treatment.

7. Wash the laundry room with water to avoid pathogen infection and mop the floor with spray.

8. Treatment and decolorization of high-difficulty wastewater.

9. Agricultural irrigation


Product parameters


Item

Unit

OS-AS10 GOX

OS-AS15 GOX

OS-AS20 GOX

OS-AS30 GOX

OS-AS60 GOX

OS-AS100 GOX

Ozone output

G/Hr

10

15

20

30

60

100

Power

W

650

750

850

1450

1650

2200

Water flow

m3/hr

1~3

1~3

1~3

3~6

3~6

6~12

Cooling way


Water /Air cooling

Feed gas source


Built-in oxygen generator source

Working voltage

V/HZ

110/220

Size

mm

55*40*130

55*40*130

55*40*130

55*40*130

90*40*150

90*40*150
