Characteristics
1.Adjustable ozone output, stable ozone output.
2.Made of Carbon steel spray or stainless steel with strong corrosion resistance and oxidation resistance.
3.Feed outside oxygen gas/ oxygen generator, high ozone concentration
4.Water cooled cooling system
5.Ceramic panel ozone generator, micro-gap discharge, high ozone concentration.
Application
1. Drinking water, mineral water, circulating cooling water, swimming circulating water, secondary water supply, industry production water, etc.
2. Sewage treatment, COD degradation, decolorization treatment, decolorization, bleaching, reclaimed water, sewage.
3.Disinfection, sterilization, deodorization and deodorization of hospital sewage and other industrial water.
Specification
| Type | Model : OS-06A-400G |
| Ozone output | 200g/hr |
| Ozone concentration | 120—170 Adjustable |
| Input voltage | 110/220 / 380V 50HZ |
| Rated power of equipment | 2.4kw |
| Feed outside oxygen flow | 50LPM |
| Oxygen purity | ≥93% |
| Cooling water | Pure water / demineralized water |
| Cooling water temperature | 15-25℃ |
| Cooling water flow | 200L/M |
| Cooling water flow | max pressure 0.8Mpa |
| Ambient temperature and humidity | 0～40/≤75 At 1 atmosphere |
| Ozone equipment size | 650×650×1660mm |
| Housing case | Spray shell |
