Product Feature:
1- High precision filter diameter more than 5 micron all kinds of suspended particles.
2- Glass fiber winding, make the sand filter more solid.
3- Good chemical corrosion resistance and UV protection.
Configuration of multi-directional valve, efficient work: Closed, Filter, Rinse, Backwash, Waster, Recirculate.
4- Equipped with rotary diaphragm pressure gauge.
5- Each sand filter has passed strict pressure testing, and can ensure safe and effective work under high pressure under the pressure of 2.5kg/cm2.
Specification:
Model | Tank Dia | Height | Valve size | Filter Area | Design flow | Silica sand |
mm | mm | m2 | m3 | kg | ||
OS-Q1200 | 1200 | 1400 | 80 | 1.15 | 56 | 850 |
OS-Q1400 | 1400 | 1580 | 100 | 1.54 | 78 | 1760 |
OS-Q1600 | 1600 | 1700 | 100 | 2.00 | 102 | 2450 |
OS-Q1800 | 1800 | 1850 | 150 | 2.54 | 126 | 3100 |
OS-Q2000 | 2000 | 2000 | 150 | 3.14 | 159 | 3800 |
OS-Q2350 | 2350 | 2350 | 200 | 4.35 | 201 | 5275 |
OS-Q2500 | 2500 | 2600 | 200 | 4.91 | 235 | 5950 |
OS-Q3000 | 3000 | 2650 | 200 | 7.06 | 350 | 8600 |
