Product feature
1. High-Purity Oxygen Production: Oxygen generators are capable of producing oxygen gas with high purity levels, often exceeding 95% 2. On-Demand Oxygen Generation: Oxygen generators can produce oxygen gas on-demand, eliminating the need for storing large quantities of oxygen in cylinders or tanks. This feature ensures a continuous and reliable supply of oxygen whenever it is required, without the risk of running out of gas.
3. Modular and Scalable Design: Many oxygen generators feature a modular design that allows for easy scalability to accommodate varying oxygen demand levels.
4. Energy-Efficient Operation: Oxygen generators are designed to operate efficiently, minimizing energy consumption and operating costs. Technologies such as pressure swing adsorption (PSA) or molecular sieve systems optimize the oxygen production process, reducing wastage and maximizing productivity.
5. Automatic Monitoring and Control: Advanced oxygen generators are equipped with built-in monitoring and control systems that ensure optimal performance and safety. These systems continuously monitor parameters such as oxygen purity, pressure, and flow rate, automatically adjusting operation parameters as needed to maintain optimal performance.
Product specification
| model | oxygen flow | power | working pressure | oxygen purity | Diameter | size |
| OS-OX02-15L | 15L/min | 1.5kw | 2~5 bar | 93%±3 | 20mm | 55*40*118cm |
| OS-OX02-20L | 20L/min | 2.2kw | 2~5 bar | 93%±3 | 20mm | 55*40*124cm |
| OS-OX02-30L | 30L/min | 3.1kw | 4~7 bar | 93%±3 | 20mm | 70*40*140cm |
| OS-OX02-40L | 40L/min | 4.7kw | 4~7 bar | 93%±3 | 20mm | 70*40*150cm |
| OS-OX02-50L | 50L/min | 5.6kw | 4~7 bar | 93%±3 | 20mm | 75*40*150cm |
| OS-OX02-60L | 60L/min | 7.5kw | 4~7 bar | 93%±3 | 20mm | 75*40*160cm |
| OS-OX02-70L | 70L/min | 9.2kw | 4~7 bar | 93%±3 | 40mm | 75*40*165cm |
| OS-OX02-100L | 100L/min | 11.8 | 4~7 bar | 93%±3 | 40mm | 75*40*170cm |
